QUATECH, INC.
ESI-100Q
|
Card Type |
I/O controller |
|
Chipset/Controller |
Zilog |
|
I/O Options |
Serial ports (4) |
|
Maximum DRAM |
None |
|
CONNECTIONS | |
|
Purpose |
Location |
|
DB-62 connector |
CN1 |
|
INTERRUPT SELECT | ||
|
IRQ |
J1 |
J2 |
|
IRQ2 |
Pins 1 & 2 closed |
N/A |
|
IRQ3 |
Pins 3 & 4 closed |
N/A |
|
IRQ4 |
Pins 5 & 6 closed |
N/A |
|
IRQ5 |
Pins 7 & 8 closed |
N/A |
|
IRQ6 |
Pins 9 & 10 closed |
N/A |
|
IRQ7 |
Pins 11 & 12 closed |
N/A |
|
IRQ10 |
N/A |
Pins 9 & 10 closed |
|
IRQ11 |
N/A |
Pins 7 & 8 closed |
|
IRQ12 |
N/A |
Pins 5 & 6 closed |
|
IRQ14 |
N/A |
Pins 3 & 4 closed |
|
IRQ15 |
N/A |
Pins 1 & 2 closed |
|
I/O ADDRESS CONFIGURATION | |||||||
|
Address Range |
SW1/2 |
SW1/3 |
SW1/4 |
SW1/5 |
SW1/6 |
SW1/7 |
SW1/8 |
|
A0000h - A1FFFh |
Off |
On |
Off |
On |
On |
On |
On |
|
A2000H - A3FFFh |
Off |
On |
Off |
On |
On |
On |
Off |
|
A4000h - A5FFFh |
Off |
On |
Off |
On |
On |
Off |
On |
|
A6000h - A7FFFh |
Off |
On |
Off |
On |
On |
Off |
Off |
|
A8000h - A9FFFh |
Off |
On |
Off |
On |
Off |
On |
On |
|
AA000h - ABFFFh |
Off |
On |
Off |
On |
Off |
On |
Off |
|
AC000h - ADFFFh |
Off |
On |
Off |
On |
Off |
Off |
On |
|
AE000h - AFFFFh |
Off |
On |
Off |
On |
Off |
Off |
Off |
|
B0000h - B1FFFh |
Off |
On |
Off |
Off |
On |
On |
On |
|
B2000h - B3FFFh |
Off |
On |
Off |
Off |
On |
On |
Off |
|
B4000h - B5FFFh |
Off |
On |
Off |
Off |
On |
Off |
On |
|
B6000h - B7FFFh |
Off |
On |
Off |
Off |
On |
Off |
Off |
|
B8000h - B9FFFh |
Off |
On |
Off |
Off |
Off |
On |
On |
|
BA000h - BBFFFh |
Off |
On |
Off |
Off |
Off |
On |
Off |
|
BC000h - BDFFFh |
Off |
On |
Off |
Off |
Off |
Off |
On |
|
BE000h -- BFFFFh |
Off |
On |
Off |
Off |
Off |
Off |
Off |
|
C0000h - C1FFFh |
Off |
Off |
On |
On |
On |
On |
On |
|
C2000h - C3FFFh |
Off |
Off |
On |
On |
On |
On |
Off |
|
C4000h - C5FFFh |
Off |
Off |
On |
On |
On |
Off |
On |
|
C6000h - C7FFFh |
Off |
Off |
On |
On |
On |
Off |
Off |
|
C8000h - C9FFFh |
Off |
Off |
On |
On |
Off |
On |
On |
|
CA000h - CBFFFh |
Off |
Off |
On |
On |
Off |
On |
Off |
|
CC000h - CDFFFh |
Off |
Off |
On |
On |
Off |
Off |
On |
|
CE000h - CFFFFh |
Off |
Off |
On |
On |
Off |
Off |
Off |
|
D0000h - D1FFFh |
Off |
Off |
On |
Off |
On |
On |
On |
|
D2000h - D3FFFh |
Off |
Off |
On |
Off |
On |
On |
Off |
|
D4000h - D5FFFh |
Off |
Off |
On |
Off |
On |
Off |
On |
|
D6000h - D7FFFh |
Off |
Off |
On |
Off |
On |
Off |
Off |
|
D8000h - D9FFFh |
Off |
Off |
On |
Off |
Off |
On |
On |
|
DA000h - DBFFFh |
Off |
Off |
On |
Off |
Off |
On |
Off |
|
DC000h - DDFFFh |
Off |
Off |
On |
Off |
Off |
Off |
On |
|
DE000h - DFFFFh |
Off |
Off |
On |
Off |
Off |
Off |
Off |
|
E0000h - E1FFFh |
Off |
Off |
Off |
On |
On |
On |
On |
|
E2000h - E3FFFh |
Off |
Off |
Off |
On |
On |
On |
Off |
|
E4000h - E5FFFh |
Off |
Off |
Off |
On |
On |
Off |
On |
|
E6000h - E7FFFh |
Off |
Off |
Off |
On |
On |
Off |
Off |
|
E8000h - E9FFFh |
Off |
Off |
Off |
On |
Off |
On |
On |
|
EA000h - EBFFFh |
Off |
Off |
Off |
On |
Off |
On |
Off |
|
EC000h - EDFFFh |
Off |
Off |
Off |
On |
Off |
Off |
On |
|
CE000h - EFFFFh |
Off |
Off |
Off |
On |
Off |
Off |
Off |
|
Note: SW1/1 is factory configured and should not be altered. Manufacturer recommended starting addresses are D0000 for board 1, D2000 for board 2, D4000 for board 3, and D6000 for board 4. | |||||||
