UNIDENTIFIED
8406 MXC
|
Card Type |
Memory card |
|
Chipset/Controller |
Unidentified |
|
I/O Options |
N/A |
|
Maximum DRAM |
16MB |
|
MEMORY BOUNDARY SWITCH SETTINGS | ||||||||
|
Memory Boundary |
SW2/1 |
SW2/2 |
SW2/3 |
SW2/4 |
SW2/5 |
SW2/6 |
SW2/7 |
SW2/8 |
|
0MB |
On |
On |
On |
On |
On |
Off |
Off |
Off |
|
2MB |
On |
On |
On |
On |
Off |
Off |
Off |
Off |
|
4MB |
On |
On |
On |
Off |
On |
Off |
Off |
Off |
|
6MB |
On |
On |
On |
Off |
Off |
Off |
Off |
Off |
|
8MB |
On |
On |
Off |
On |
On |
Off |
Off |
Off |
|
12MB |
On |
On |
Off |
Off |
On |
Off |
Off |
Off |
|
16MB |
On |
Off |
On |
On |
On |
Off |
Off |
Off |
|
20MB |
On |
Off |
On |
Off |
On |
Off |
Off |
Off |
|
24MB |
On |
Off |
Off |
On |
On |
Off |
Off |
Off |
|
28MB |
On |
Off |
Off |
Off |
On |
Off |
Off |
Off |
|
32MB |
Off |
On |
On |
On |
On |
Off |
Off |
Off |
|
36MB |
Off |
On |
On |
Off |
On |
Off |
Off |
Off |
|
40MB |
Off |
On |
Off |
On |
On |
Off |
Off |
Off |
|
44MB |
Off |
On |
Off |
Off |
On |
Off |
Off |
Off |
|
48MB |
Off |
Off |
On |
On |
On |
Off |
Off |
Off |
|
52MB |
Off |
Off |
On |
Off |
On |
Off |
Off |
Off |
|
56MB |
Off |
Off |
Off |
On |
On |
Off |
Off |
Off |
|
60MB |
Off |
Off |
Off |
Off |
On |
Off |
Off |
Off |
|
MEMORY BOUNDARY SWITCH SETTINGS(CONTINUED) | ||||||||
|
Memory Boundary |
SW3/1 |
SW3/2 |
SW3/3 |
SW3/4 |
SW3/5 |
SW3/6 |
SW3/7 |
SW3/8 |
|
0MB |
On |
On |
On |
On |
On |
On |
On |
On |
|
2MB |
Off |
Off |
Off |
Off |
Off |
Off |
Off |
Off |
|
4MB |
On |
On |
On |
On |
On |
On |
On |
On |
|
6MB |
Off |
Off |
Off |
Off |
Off |
Off |
Off |
Off |
|
8MB |
On |
On |
On |
On |
On |
On |
On |
On |
|
12MB |
On |
On |
On |
On |
On |
On |
On |
On |
|
16MB |
On |
On |
On |
On |
On |
On |
On |
On |
|
20MB |
On |
On |
On |
On |
On |
On |
On |
On |
|
24MB |
On |
On |
On |
On |
On |
On |
On |
On |
|
28MB |
On |
On |
On |
On |
On |
On |
On |
On |
|
32MB |
On |
On |
On |
On |
On |
On |
On |
On |
|
36MB |
On |
On |
On |
On |
On |
On |
On |
On |
|
40MB |
On |
On |
On |
On |
On |
On |
On |
On |
|
44MB |
On |
On |
On |
On |
On |
On |
On |
On |
|
48MB |
On |
On |
On |
On |
On |
On |
On |
On |
|
52MB |
On |
On |
On |
On |
On |
On |
On |
On |
|
56MB |
On |
On |
On |
On |
On |
On |
On |
On |
|
60MB |
On |
On |
On |
On |
On |
On |
On |
On |
|
DRAM CONFIGURATION | ||||
|
Size |
Bank 0 |
Bank 1 |
Bank 2 |
Bank 3 |
|
2MB |
(4) 512K x 9 |
NONE |
NONE |
NONE |
|
4MB |
(4) 512K x 9 |
(4) 512K x 9 |
NONE |
NONE |
|
4MB |
(4) 1M x 9 |
NONE |
NONE |
NONE |
|
6MB |
(4) 512K x 9 |
(4) 512K x 9 |
(4) 512K x 9 |
NONE |
|
6MB |
(4) 512K x 9 |
(4) 1M x 9 |
N/A |
NONE |
|
8MB |
(4) 512K x 9 |
(4) 512K x 9 |
(4) 512K x 9 |
(4) 512K x 9 |
|
8MB |
(4) 512K x 9 |
(4) 512K x 9 |
(4) 1M x 9 |
NONE |
|
8MB |
(4) 1M x 9 |
(4) 1M x 9 |
NONE |
NONE |
|
10MB |
(4) 1M x 9 |
(4) 512K x 9 |
(4) 512K x 9 |
(4) 512K x 9 |
|
10MB |
(4) 512K x 9 |
(4) 1M x 9 |
(4) 1M x 9 |
NONE |
|
12MB |
(4) 512K x 9 |
(4) 512K x 9 |
(4) 1M x 9 |
(4) 1M x 9 |
|
12MB |
(4) 1M x 9 |
(4) 1M x 9 |
(4) 1M x 9 |
NONE |
|
14MB |
(4) 512K x 9 |
(4) 1M x 9 |
(4) 1M x 9 |
(4) 1M x 9 |
|
16MB |
(4) 1M x 9 |
(4) 1M x 9 |
(4) 1M x 9 |
(4) 1M x 9 |
|
DRAM SWITCH SETTINGS | ||||
|
Memory Module |
Bank 0 |
Bank 1 |
Bank 2 |
Bank 3 |
|
Installed |
SW1/1 |
SW1/2 |
SW1/3 |
SW1/4 |
|
NONE |
On |
On |
On |
On |
|
512KB |
Off |
Off |
Off |
Off |
|
1MB |
On |
On |
On |
On |
|
DRAM SWITCH SETTINGS(CONTINUED) | ||||
|
Bank 0 |
Bank 1 |
Bank 2 |
Bank 3 | |
|
Setting |
SW1/5 |
SW1/6 |
SW1/7 |
SW1/8 |
|
Enabled |
On |
On |
On |
On |
|
Disabled |
Off |
Off |
Off |
Off |
|
MEMORY ADDRESS RANGE | |||
|
Address Range |
JP2 |
JP3 | |
| » |
7C0000 - 7F0000h |
Pins 2 & 3 closed |
Pins 1 & 2 closed |
|
FA0000 - FD0000h |
Pins 1 & 2 closed |
Pins 2 & 3 closed | |
|
PARITY CHECK | ||
|
Setting |
JP5 | |
| » |
Enabled |
Pins 2 & 3 closed |
|
Disabled |
Pins 1 & 2 closed | |
|
FACTORY CONFIGURED SETTINGS | |
|
Jumper |
Setting |
|
JP1 |
Pins 1 & 2 closed |
