Card Type	Memory card
Maximum Onboard Memory	1MB DRAM
Data Bus	16-bit ISA
Card Size	Full-length, full-height card

USER CONFIGURABLE SETTINGS
Function	Label	Position
EMS enabled	SW1/3	On
EMS disabled	SW1/3	Off
Base system memory = 512KB	SW1/4	Off
Base system memory = 640KB	SW1/4	On

MEMORY BOARD NUMBER SELECTION
Board number	SW1/1	SW1/2
0	On	On
1	On	Off
2	Off	On
3	Off	Off

BASE ADDRESS SELECTION
Memory block	SW1/5	SW1/6	SW1/7	SW1/8
0	On	On	On	On
1	Off	On	On	On
2	On	Off	On	On
3	Off	Off	On	On
4	On	On	Off	On
5	Off	On	Off	On
6	On	Off	Off	On
7	Off	Off	Off	On
8	On	On	On	Off
9	Off	On	On	Off
10	On	Off	On	Off
11	Off	Off	On	Off
12	On	On	Off	Off
13	Off	On	Off	Off
14	On	Off	Off	Off
15	Off	Off	Off	Off
