ANCO TECHNOLOGY, INC.
E5001
|
NIC Type |
Ethernet |
|
Transfer Rate |
10Mbps |
|
Data Bus |
8-bit ISA |
|
Topology |
Star |
|
Wiring Type |
Unshielded twisted pair AUI transceiver via DB-15 port |
|
Boot ROM |
Available |
|
INTERRUPT REQUEST | ||||||
|
IRQ |
JP1A |
JP1B |
JP1C |
JP1D |
JP1E | |
|
2/9 |
Closed |
Open |
Open |
Open |
Open | |
| » |
3 |
Open |
Closed |
Open |
Open |
Open |
|
6 |
Open |
Open |
Closed |
Open |
Open | |
|
6 |
Open |
Open |
Open |
Closed |
Open | |
|
7 |
Open |
Open |
Open |
Open |
Closed | |
|
CABLE TYPE | ||
|
Type |
SW1/1 | |
| » |
Unshielded twisted pair |
On |
|
AUI transceiver via DB-15 port |
Off | |
|
LINK INTEGRITY TEST | ||
|
Setting |
JP31 | |
| » |
Enabled |
Pins 1 & 2 Closed |
|
Disabled |
Pins 2 & 3 Closed | |
|
Note:Link Integrity is only used with 10Base-T wiring. When using an AUI transciever, the test should be disabled. | ||
|
I/O BASE ADDRESS | |||
|
Address |
SW1/3 |
SW1/4 | |
| » |
300-31Fh |
On |
On |
|
320-33Fh |
Off |
On | |
|
340-35Fh |
On |
Off | |
|
360-37Fh |
Off |
Off | |
|
BOOT ROM ADDRESS | ||||
|
Address |
SW1/5 |
SW1/6 |
SW1/7 |
SW1/8 |
|
Disabled |
Off |
Off |
Off |
Off |
|
C4000h |
On |
On |
On |
Off |
|
C8000h |
Off |
On |
On |
Off |
|
CC000h |
On |
Off |
On |
Off |
|
D0000h |
Off |
Off |
On |
Off |
|
D4000h |
On |
On |
Off |
Off |
|
D8000h |
Off |
On |
Off |
Off |
|
DC000h |
On |
Off |
Off |
Off |
|
DIAGNOSTIC LED(S) | |||
|
LED |
Link Integrity |
Status |
Condition |
|
LED1 |
Enabled |
On |
Twisted pair network connection good |
|
LED1 |
Enabled |
Off |
Twisted pair network connection broken |
|
LED1 |
Disabled |
On |
Data is being received power |
|
LED1 |
Disabled |
Off |
Data is not being received power |
|
Note:The condition shown by LED1 depends on the setting of the link integrity test switch SW1/2. (see above) | |||
