NIC Type	Ethernet
Transfer Rate	10Mbps
Data Bus	32-Bit NuBus (Apple)
Topology	Star Linear Bus
Wiring Type	Shielded/Unshielded twisted pair RG58A/U 50ohm coaxial
Boot ROM	Not Available

CABLE TYPE
Type		JP1
»	Shielded/Unshielded twisted pair	Open
	RG-58A/U 50ohm coaxial	Closed

LINK STATUS TEST
Link Status Test		JP2
»	Enabled	Off
	Disabled	On
Note: If the network is pre-10BASE-T, you will need to disabled the link status test.

SQE (SIGNAL QUALITY ERROR) ENABLE/DISABLE
Condition		JP3
»	SQE enabled	Closed
	SQE disabled	Open
Note: When using Shielded/Unshielded twisted pair, SQE should be disabled.

CABLE TYPE
Condition		JP4
»	Shielded/Unshielded twisted pair	Closed
	RG-58A/U 50ohm coaxial	Open

FACTORY CONFIGURED SETTINGS
Jumper	Setting
JP5	Unknown
