EDIMAX COMPUTER COMPANY

AL-3353/AL-3354

NIC Type

ARCnet

Transfer Rate

2.5Mbps

Data Bus

16-bit ISA

Topology

Star

Linear Bus

Wiring Type

RG-62A/U 93ohm coaxial

Unshielded twisted pair

Boot ROM

Available

NODE ID ADDRESS

Node

SW1/1

SW1/2

SW1/3

SW1/4

SW1/5

SW1/6

SW1/7

SW1/8

0

-

-

-

-

-

-

-

-

1

Off

On

On

On

On

On

On

On

2

On

Off

On

On

On

On

On

On

3

Off

Off

On

On

On

On

On

On

4

On

On

Off

On

On

On

On

On

251

Off

Off

On

Off

Off

Off

Off

Off

252

On

On

Off

Off

Off

Off

Off

Off

253

Off

On

Off

Off

Off

Off

Off

Off

254

On

Off

Off

Off

Off

Off

Off

Off

255

Off

Off

Off

Off

Off

Off

Off

Off

Notes:Node address 0 is used for messaging between nodes and must not be used. A total of 255 node address settings are available. The switches are a binary representation of the decimal node addresses. Switch 1 is the Least Significant Bit and switch 8 is the Most Significant Bit. The switches have the following decimal values: switch 1=1, 2=2, 3=4, 4=8, 5=16, 6=32, 7=64, 8=128. Turn off the switches and add the values of the off switches to obtain the correct node address. (On=0, Off=1)

CABLE TYPE & TOPOLOGY

Type

Topology

JP7

JP8

JP10

JP12

Coaxial

Star

Closed

Open

Open

Open

Coaxial

Linear Bus

Open

Closed

Open

Open

Twisted pair

Star

Open

Open

Closed

Closed

Twisted pair

Linear Bus

Open

Open

Closed

Closed

BASE MEMORY ADDRESS

Address

JP5A & JP5B

SW2/7

SW2/8

SW2/9

SW2/10

C0000h

Closed

Off

Off

On

On

CC000h

Open

Off

Off

On

On

D0000h

Closed

Off

Off

On

Off

DC000h

Open

Off

Off

On

Off

E0000h

Closed

Off

Off

Off

On

INTERRUPT SETTINGS

IRQ

JP6A

JP6B

JP6C

JP6D

JP6E

JP6F

JP6G

JP6H

JP6I

JP6J

JP6K

2

Open

Open

Open

Open

Open

Closed

Open

Open

Open

Open

Open

3

Closed

Open

Open

Open

Open

Open

Open

Open

Open

Open

Open

4

Open

Closed

Open

Open

Open

Open

Open

Open

Open

Open

Open

5

Open

Open

Closed

Open

Open

Open

Open

Open

Open

Open

Open

6

Open

Open

Open

Closed

Open

Open

Open

Open

Open

Open

Open

7

Open

Open

Open

Open

Closed

Open

Open

Open

Open

Open

Open

10

Open

Open

Open

Open

Open

Open

Closed

Open

Open

Open

Open

11

Open

Open

Open

Open

Open

Open

Open

Closed

Open

Open

Open

12

Open

Open

Open

Open

Open

Open

Open

Open

Closed

Open

Open

14

Open

Open

Open

Open

Open

Open

Open

Open

Open

Closed

Open

15

Open

Open

Open

Open

Open

Open

Open

Open

Open

Open

Closed

RESPONSE AND RECONFIGURATION TIMEOUTS

Response Time

Idle Time

Reconfiguration Time

JP9

JP11

»

78µs

86µs

840ms

Open

Open



285µs

316µs

1680ms

Open

Closed



563µs

624µs

1680ms

Closed

Open



1130µs

1237µs

1680ms

Closed

Closed

Note:All NICs on the network segment must have this option set the same.

I/O BASE ADDRESS

Address

SW2/1

SW2/2

SW2/3

SW2/4

SW2/5

SW2/6

»

2E0h

Off

On

Off

Off

Off

On



2F0h

Off

On

Off

Off

Off

Off



300h

Off

Off

On

On

On

On



350h

Off

Off

On

Off

On

Off

DIAGNOSTIC LED(S)

LED

Color

Status

Condition

LED1

Green

Blinking

Data is being transmitted or received

LED1

Green

Off

Data is not being transmitted or received

MISCELLANEOUS NOTES

The AL-3353 and the AL-3354 have different transceivers. As a result the AL-3353 should only be operated in a coaxial star configuration, while the AL-3354 will operate in a coaxial bus, a coaxial star, a twisted pair bus or a twisted pair star configuration.
