EDIMAX COMPUTER COMPANY
AL-3350
|
NIC Type |
Arcrnet |
|
Transfer Rate |
2.5Mbps |
|
Data Bus |
8-bit ISA |
|
Topology |
Linear Bus |
|
Wiring Type |
RG-62A/U 93ohm coaxial |
|
Boot ROM |
Available |
|
NODE ID ADDRESS |
||||||||
|
Node |
SW1/1 |
SW1/2 |
SW1/3 |
SW1/4 |
SW1/5 |
SW1/6 |
SW1/7 |
SW1/8 |
|
0 |
- |
- |
- |
- |
- |
- |
- |
- |
|
1 |
Off |
On |
On |
On |
On |
On |
On |
On |
|
2 |
On |
Off |
On |
On |
On |
On |
On |
On |
|
3 |
Off |
Off |
On |
On |
On |
On |
On |
On |
|
4 |
On |
On |
Off |
On |
On |
On |
On |
On |
|
251 |
Off |
Off |
On |
Off |
Off |
Off |
Off |
Off |
|
252 |
On |
On |
Off |
Off |
Off |
Off |
Off |
Off |
|
253 |
Off |
On |
Off |
Off |
Off |
Off |
Off |
Off |
|
254 |
On |
Off |
Off |
Off |
Off |
Off |
Off |
Off |
|
255 |
Off |
Off |
Off |
Off |
Off |
Off |
Off |
Off |
|
Note:Node address 0 is used for messaging between nodes and must not be used. A total of 255 node address settings are available. The switches are a binary representation of the decimal node addresses. Switch 1 is the Least Significant Bit and switch 8 is the Most Significant Bit. The switches have the following decimal values: switch 1=1, 2=2, 3=4, 4=8, 5=16, 6=32, 7=64, 8=128. Turn off the switches and add the values of the off switches to obtain the correct node address. (On=0, Off=1) |
||||||||
|
TOPOLOGY/CABLE TYPE |
||||
|
Type |
BJP/1 |
BJP/2 |
BJP/3 |
BJP/4 |
|
Star/BNC |
Open |
Open |
Open |
Closed |
|
Bus/BNC |
Open |
Open |
Closed |
Open |
|
Star/UTP |
Closed |
Closed |
Open |
Open |
|
BASE MEMORY ADDRESS & BOOT ROM ADDRESS |
|||||||
|
Base Address |
Boot ROM |
JP1/1 |
JP1/2 |
JP1/3 |
JP1/4 |
JP1/5 |
|
|
» |
D0000-D07FFh |
D2000-D3FFFh |
Closed |
Closed |
Open |
Open |
Closed |
|
C0000-C07FFh |
C2000-C3FFFh |
Closed |
Closed |
Closed |
Closed |
Closed |
|
|
C0800-C0FFFh |
C2000-C3FFFh |
Open |
Closed |
Closed |
Closed |
Closed |
|
|
C1000-C17FFh |
C2000-C3FFFh |
Closed |
Open |
Closed |
Closed |
Closed |
|
|
C1800-C1FFFh |
C2000-C3FFFh |
Open |
Open |
Closed |
Closed |
Closed |
|
|
C4000-C47FFh |
C6000-C7FFFh |
Closed |
Closed |
Open |
Closed |
Closed |
|
|
C4800-C4FFFh |
C6000-C7FFFh |
Open |
Closed |
Open |
Closed |
Closed |
|
|
C5000-C57FFh |
C6000-C7FFFh |
Closed |
Open |
Open |
Closed |
Closed |
|
|
C5800-C5FFFh |
C6000-C7FFFh |
Open |
Open |
Open |
Closed |
Closed |
|
|
CC000-CC7FFh |
CE000-CFFFFh |
Closed |
Closed |
Closed |
Open |
Closed |
|
|
CC800-CCFFFh |
CE000-CFFFFh |
Open |
Closed |
Closed |
Open |
Closed |
|
|
CD000-CD7FFh |
CE000-CFFFFh |
Closed |
Open |
Closed |
Open |
Closed |
|
|
CD800-CDFFFh |
CE000-CFFFFh |
Open |
Open |
Closed |
Open |
Closed |
|
|
D0800-D0FFFh |
D2000-D3FFFh |
Open |
Closed |
Open |
Open |
Closed |
|
|
D1000-D17FFh |
D2000-D3FFFh |
Closed |
Open |
Open |
Open |
Closed |
|
|
D1800-D1FFFh |
D2000-D3FFFh |
Open |
Open |
Open |
Open |
Closed |
|
|
D4000-D47FFh |
D6000-D7FFFh |
Closed |
Closed |
Closed |
Closed |
Open |
|
|
D4800-D4FFFh |
D6000-D7FFFh |
Open |
Closed |
Closed |
Closed |
Open |
|
|
D5000-D57FFh |
D6000-D7FFFh |
Closed |
Open |
Closed |
Closed |
Open |
|
|
D5800 D5FFFh |
D6000-D7FFFh |
Open |
Open |
Closed |
Closed |
Open |
|
|
D8000-D87FFh |
DA000-DBFFFh |
Closed |
Closed |
Open |
Closed |
Open |
|
|
D8800-D8FFFh |
DA000-DBFFFh |
Open |
Closed |
Open |
Closed |
Open |
|
|
D9000-D97FFh |
DA000-DBFFFh |
Closed |
Open |
Open |
Closed |
Open |
|
|
D9800-D9FFFh |
DA000-DBFFFh |
Open |
Open |
Open |
Closed |
Open |
|
|
DC000-DC7FFh |
DE000-DFFFFh |
Closed |
Closed |
Closed |
Open |
Open |
|
|
DC800-DCFFFh |
DE000-DFFFFh |
Open |
Closed |
Closed |
Open |
Open |
|
|
DD000-DD7FFh |
DE000-DFFFFh |
Closed |
Open |
Closed |
Open |
Open |
|
|
DD800-DDFFFh |
DE000-DFFFFh |
Open |
Open |
Closed |
Open |
Open |
|
|
E0000-E07FFh |
E2000-E3FFFh |
Closed |
Closed |
Open |
Open |
Open |
|
|
E0800-E0FFFh |
E2000-E3FFFh |
Open |
Closed |
Open |
Open |
Open |
|
|
E1000-E17FFh |
E2000-E3FFFh |
Closed |
Open |
Open |
Open |
Open |
|
|
E1800-E1FFFh |
E2000-E3FFFh |
Open |
Open |
Open |
Open |
Open |
|
|
I/O BASE ADDRESS |
||||
|
Address |
JP1/6 |
JP1/7 |
JP1/8 |
|
|
» |
2E0-2EFh |
Closed |
Open |
Closed |
|
|
260-26Fh |
Closed |
Closed |
Closed |
|
|
290-29Fh |
Open |
Closed |
Closed |
|
|
2F0-2EFh |
Open |
Open |
Closed |
|
300-30Fh |
Closed |
Closed |
Open |
|
|
|
350-35Fh |
Open |
Closed |
Open |
|
|
380-38Fh |
Closed |
Open |
Open |
|
|
3E0-3EFh |
Open |
Open |
Open |
|
RESPONSE AND RECONFIGURATION TIMEOUTS |
|||||
|
Response Time |
Idle Time |
Reconfiguration Time |
JP4/1 |
JP4/2 |
|
|
» |
78µs |
86µs |
840ms |
Open |
Open |
|
285µs |
316µs |
1680ms |
Open |
Closed |
|
|
563µs |
624µs |
1680ms |
Closed |
Open |
|
|
1130µs |
1237µs |
1680ms |
Closed |
Closed |
|
|
Note: All NICs on the network segment must have this option set the same. |
|||||
|
ONBOARD TERMINATOR |
||||
|
Terminator |
AJP/1 |
AJP/2 |
AJP/3 |
AJP/4 |
|
Coaxial Bus Terminated |
Open |
Closed |
Open |
Closed |
|
Twisted Pair Terminated |
Closed |
Open |
Closed |
Open |
|
BOOT ROM |
||
|
Setting |
JP3 |
|
|
» |
Disabled |
Open |
|
|
Enabled |
Closed |
|
INTERRUPT REQUEST |
||||||
|
IRQ |
JP2/1 |
JP2/2 |
JP2/3 |
JP2/4 |
JP2/5 |
|
|
» |
2 |
Closed |
Open |
Open |
Open |
Open |
|
|
3 |
Open |
Closed |
Open |
Open |
Open |
|
|
4 |
Open |
Open |
Closed |
Open |
Open |
|
|
5 |
Open |
Open |
Open |
Closed |
Open |
|
|
7 |
Open |
Open |
Open |
Open |
Closed |
|
DIAGNOSTIC LED(S) |
|||
|
LED |
Color |
Status |
Condition |
|
LED1 |
Green |
Blinking |
Data is being transmitted/received |
|
LED1 |
Green |
Off |
Data is not being transmitted/received |
