INVISIBLE SOFTWARE, INC.
ETHERNET 2000RA
|
NIC Type |
Ethernet |
|
Transfer Rate |
10Mbps |
|
Data Bus |
16-bit ISA |
|
Topology |
Linear Bus/Star |
|
Wiring Type |
Unshielded twisted pair RG-58A/U 50ohm coaxial |
|
Boot ROM |
Available |
|
BASE I/O ADDRESS SELECTION |
||||
|
Address |
JP1/A |
JP1/B |
JP1/C |
|
|
» |
300h |
Open |
Open |
Open |
|
200h |
Open |
Open |
Closed |
|
|
220h |
Closed |
Open |
Closed |
|
|
240h |
Open |
Closed |
Closed |
|
|
260h |
Closed |
Closed |
Closed |
|
|
320h |
Closed |
Open |
Open |
|
|
340h |
Open |
Closed |
Open |
|
|
360h |
Closed |
Closed |
Open |
|
|
INTERRUPT SELECTION |
|||||||||
|
IRQ |
JP2/A |
JP2/B |
JP2/C |
JP2/D |
JP2/E |
JP2/F |
JP2/G |
JP2/H |
|
|
» |
3 |
Open |
Open |
Open |
Open |
Open |
Open |
Closed |
Open |
|
2 |
Open |
Open |
Open |
Open |
Open |
Open |
Open |
Closed |
|
|
4 |
Open |
Open |
Open |
Open |
Open |
Closed |
Open |
Open |
|
|
5 |
Open |
Open |
Open |
Open |
Closed |
Open |
Open |
Open |
|
|
10 |
Open |
Open |
Open |
Closed |
Open |
Open |
Open |
Open |
|
|
11 |
Open |
Open |
Closed |
Open |
Open |
Open |
Open |
Open |
|
|
12 |
Open |
Closed |
Open |
Open |
Open |
Open |
Open |
Open |
|
|
15 |
Closed |
Open |
Open |
Open |
Open |
Open |
Open |
Open |
|
|
CONFIGURATION TYPE SELECTION |
||
|
Setting |
JP2/I |
|
|
» |
Software configured |
Closed |
|
Hardware configured |
Open |
|
|
BOOT ROM CONFIGURATION |
||
|
Setting |
JP1/G |
|
|
» |
Disabled |
Open |
|
Enabled |
Closed |
|
|
ROM ADDRESS |
||||
|
Address |
JP1/D |
JP1/E |
JP1/F |
|
|
» |
C800h |
Open |
Closed |
Open |
|
C000h |
Open |
Open |
Open |
|
|
C400h |
Closed |
Open |
Open |
|
|
CC00h |
Closed |
Closed |
Open |
|
|
D000h |
Open |
Open |
Closed |
|
|
D400h |
Closed |
Open |
Closed |
|
|
D800h |
Open |
Closed |
Closed |
|
|
DC00h |
Closed |
Closed |
Closed |
|
|
DIAGNOSTIC LED(S) |
|||
|
LED |
Color |
Status |
Condition |
|
LED1 |
Yellow |
On |
Network connection is good |
|
LED1 |
Yellow |
Off |
Network connection is broken |
|
LED2 |
Green |
Blinking |
Data is being transmitted/received |
|
LED2 |
Green |
Off |
Data is not being transmitted/received |
|
MISCELLANEOUS NOTES |
|
Note: Bar code on back of card reads, "2000RAnnnnnnnnn". |
