NIC Type	Ethernet
Network Transfer Rate	10Mbps
Data Bus	16-bit ISA
Topology	Linear Bus, Star
Wiring Type	Unshielded twisted pair AUI transceiver via DB-15 port RG-58A/U 50ohm coaxial
Boot ROM	Available

COPENNECTIOPENS
Function	Label	Function	Label
AUI transceiver via DB-15 port	CN1	RG-58A/U 50ohm coaxial port	CN3
Unshielded twisted pair port	CN2

BASE I/O ADDRESS SELECTIOPEN
Address		JP2/A	JP2/B	JP2/C
	200h	Open	Open	Closed
	220h	Closed	Open	Closed
	240h	Open	Closed	Closed
	260h	Closed	Closed	Closed
»	300h	Open	Open	Open
	320h	Closed	Open	Open
	340h	Open	Closed	Open
	360h	Closed	Closed	Open

INTERRUPT SELECTIOPEN
IRQ	JP1/A	JP1/B	JP1/C	JP1/D	JP1/E	JP1/F	JP1/G	JP1/H	JP1/I
Jumperless	Open	Open	Open	Open	Open	Open	Open	Open	Closed
2	Open	Open	Open	Open	Open	Open	Open	Closed	Open
3	Open	Open	Open	Open	Open	Open	Closed	Open	Open
4	Open	Open	Open	Open	Open	Closed	Open	Open	Open
5	Open	Open	Open	Open	Closed	Open	Open	Open	Open
10	Open	Open	Open	Closed	Open	Open	Open	Open	Open
11	Open	Open	Closed	Open	Open	Open	Open	Open	Open
12	Open	Closed	Open	Open	Open	Open	Open	Open	Open
15	Closed	Open	Open	Open	Open	Open	Open	Open	Open

BOOT ROM COPENFIGURATIOPEN
Setting	JP2
Enabled	Closed
Disabled	Open

BOOT ROM JUMPER COPENFIGURATIOPEN
Setting		JP2/D	JP2/E	JP2/F	JP2/G
	C000h	Open	Open	Open	Closed
	C400h	Closed	Open	Open	Closed
	C800h	Open	Closed	Open	Closed
	CC00h	Closed	Closed	Open	Closed
»	D000h	Open	Open	Closed	Closed
	D400h	Closed	Open	Closed	Closed
	D800h	Open	Closed	Closed	Closed
	DC00h	Closed	Closed	Closed	Closed
