INVISIBLE SOFTWARE, INC.
ETHERNET VL3200 V2.0
|
Card Type |
Network Interface Card |
|
NIC Type |
Ethernet |
|
Maximum Onboard Memory |
32Kb |
|
Boot ROM |
Available |
|
Network Transfer Rate |
10Mbps |
|
Topology |
Linear Bus, Star |
|
Wiring Type |
RJ-45 Unshielded twisted pair, AUI, RG-58A/U 50ohm coaxial |
|
Data Bus |
32-bit VESA |
|
CONNECTIONS |
|||
|
Function |
Label |
Function |
Label |
|
UTP connector (RJ-45) |
CN1 |
AUI port |
CN3 |
|
BNC connector |
CN2 |
|
|
|
USER CONFIGURABLE SETTINGS |
||
|
Function |
Label |
Position |
|
16-bit bus size |
JP1 |
Pins 1 & 2 closed |
|
32-bit bus size |
JP1 |
Pins 2 & 3 closed |
|
180M trunk segment selected (BNC only) |
JP9 |
Closed |
|
300M trunk segment selected (BNC only) |
JP9 |
Open |
|
BASE I/O ADDRESS SELECTION |
||||
|
Setting |
JP5/A |
JP5/B |
JP5/C |
|
|
|
200h |
Open |
Closed |
Closed |
|
|
220h |
Closed |
Closed |
Closed |
|
|
280h |
Open |
Open |
Closed |
|
» |
300h |
Open |
Open |
Open |
|
|
320h |
Closed |
Open |
Open |
|
|
340h |
Open |
Closed |
Open |
|
|
360h |
Closed |
Closed |
Open |
|
INTERRUPT SELECTION |
|||||||
|
IRQ |
JP6/A |
JP6/B |
JP6/C |
JP6/D |
JP6/E |
JP6/F |
|
|
|
2 |
Closed |
Open |
Open |
Open |
Open |
Open |
|
» |
3 |
Open |
Closed |
Open |
Open |
Open |
Open |
|
|
4 |
Open |
Open |
Closed |
Open |
Open |
Open |
|
|
5 |
Open |
Open |
Open |
Closed |
Open |
Open |
|
|
6 |
Open |
Open |
Open |
Open |
Closed |
Open |
|
|
7 |
Open |
Open |
Open |
Open |
Open |
Closed |
|
|
10 |
Open |
Open |
Open |
Open |
Open |
Open |
|
|
11 |
Open |
Open |
Open |
Open |
Open |
Open |
|
|
12 |
Open |
Open |
Open |
Open |
Open |
Open |
|
|
14 |
Open |
Open |
Open |
Open |
Open |
Open |
|
|
15 |
Open |
Open |
Open |
Open |
Open |
Open |
|
INTERRUPT SELECTION CONTINUED |
||||||
|
IRQ |
JP7/A |
JP7/B |
JP7/C |
JP7/D |
JP7/E |
|
|
|
2 |
Open |
Open |
Open |
Open |
Open |
|
» |
3 |
Open |
Open |
Open |
Open |
Open |
|
|
4 |
Open |
Open |
Open |
Open |
Open |
|
|
5 |
Open |
Open |
Open |
Open |
Open |
|
|
6 |
Open |
Open |
Open |
Open |
Open |
|
|
7 |
Open |
Open |
Open |
Open |
Open |
|
|
10 |
Closed |
Open |
Open |
Open |
Open |
|
|
11 |
Open |
Closed |
Open |
Open |
Open |
|
|
12 |
Open |
Open |
Closed |
Open |
Open |
|
|
14 |
Open |
Open |
Open |
Closed |
Open |
|
|
15 |
Open |
Open |
Open |
Open |
Closed |
|
CABLE TYPE SELECTION |
||||||
|
Type |
JP8/A |
JP8/B |
JP8/C |
JP8/D |
JP8/E |
JP8/F |
|
AUI |
Open |
Open |
Open |
Open |
Open |
Open |
|
RG-58A/U 50ohm coaxial |
1 & 2 |
1 & 2 |
1 & 2 |
1 & 2 |
1 & 2 |
1 & 2 |
|
Unshielded twisted pair |
2 & 3 |
2 & 3 |
2 & 3 |
2 & 3 |
2 & 3 |
2 & 3 |
|
Note: Designated pins are closed |
||||||
|
ROM SIZE SELECTION |
||
|
Size |
JP2 |
JP3 |
|
16K |
Pins 1 & 2 closed |
Pins 1 & 2 closed |
|
32K |
Pins 2 & 3 closed |
Pins 2 & 3 closed |
|
ROM ADDRESS SELECTION |
||||||||
|
Address |
JP4/A |
JP4/B |
JP4/C |
JP4/D |
JP4/E |
JP4/F |
JP4/G |
JP4/H |
|
C000h |
Closed |
Open |
Open |
Open |
Open |
Open |
Open |
Open |
|
C400h |
Open |
Closed |
Open |
Open |
Open |
Open |
Open |
Open |
|
C800h |
Open |
Open |
Closed |
Open |
Open |
Open |
Open |
Open |
|
CC00h |
Open |
Open |
Open |
Closed |
Open |
Open |
Open |
Open |
|
D000h |
Open |
Open |
Open |
Open |
Closed |
Open |
Open |
Open |
|
D400h |
Open |
Open |
Open |
Open |
Open |
Closed |
Open |
Open |
|
D800h |
Open |
Open |
Open |
Open |
Open |
Open |
Closed |
Open |
|
DC00h |
Open |
Open |
Open |
Open |
Open |
Open |
Open |
Closed |
|
Disabled |
Open |
Open |
Open |
Open |
Open |
Open |
Open |
Open |
