NIC Type	Ethernet
Transfer Rate	2Mbps
Data Bus	8/16-bit ISA
Topology	Star
Wiring Type	RF Antenna (902 - 928MHz)
Boot ROM	Available

I/O BASE ADDRESS
Address		SW1/1	SW1/2
»	300h	Off	Off
	390h	Off	On
	3C0h	On	Off
	3E0h	On	On

BOOT ROM ADDRESS
Address		SW2/3	SW2/4
»	Disabled	Off	Off
	C8000h	Off	On
	D0000h	On	Off
	D8000h	On	On

MISCELLANEOUS NOTES

The DES is an optional Data Encryption Security chip available from the manufacturer. If one card uses the DES chip, all cards must use the chip.
