STANDARD MICROSYSTEMS CORPORATION
ETHERNET 3008TP
|
NIC Type |
Ethernet |
|
Transfer Rate |
10Mbps |
|
Data Bus |
8-bit ISA |
|
Topology |
Linear Bus Star |
|
Wiring Type |
Unshielded twisted pair AUI transceiver via DB-15 port |
|
Boot ROM |
Available |
|
I/O BASE ADDRESS | ||||||||
|
Address |
SW1/1 |
SW1/2 |
SW1/3 |
SW1/4 |
SW1/5 |
SW1/6 |
SW1/7 | |
| » |
300h |
On |
On |
On |
Off |
Off |
On |
On |
|
200h |
On |
On |
On |
On |
Off |
On |
On | |
|
220h |
Off |
On |
On |
On |
Off |
On |
On | |
|
240h |
On |
Off |
On |
On |
Off |
On |
On | |
|
260h |
Off |
Off |
On |
On |
Off |
On |
On | |
|
280h |
On |
On |
Off |
On |
Off |
On |
On | |
|
2A0h |
Off |
On |
Off |
On |
Off |
On |
On | |
|
2C0h |
On |
Off |
Off |
On |
Off |
On |
On | |
|
2E0h |
Off |
Off |
Off |
On |
Off |
On |
On | |
|
320h |
Off |
On |
On |
Off |
Off |
On |
On | |
|
340h |
On |
Off |
On |
Off |
Off |
On |
On | |
|
360h |
Off |
Off |
On |
Off |
Off |
On |
On | |
|
380h |
On |
On |
Off |
Off |
Off |
On |
On | |
|
3A0h |
Off |
On |
Off |
Off |
Off |
On |
On | |
|
3C0h |
On |
Off |
Off |
Off |
Off |
On |
On | |
|
3E0h |
Off |
Off |
Off |
Off |
Off |
On |
On | |
|
BOOT ROM | ||
|
Setting |
SW1/8 | |
| » |
Disabled |
Off |
|
Enabled |
On | |
|
BASE MEMORY ADDRESS | |||||||
|
Address |
SW2/1 |
SW2/2 |
SW2/3 |
SW2/4 |
SW2/5 |
SW2/6 | |
| » |
D0000h |
On |
On |
Off |
On |
Off |
Off |
|
C0000h |
On |
On |
On |
On |
Off |
Off | |
|
C4000h |
Off |
On |
On |
On |
Off |
Off | |
|
C8000h |
On |
Off |
On |
On |
Off |
Off | |
|
CC000h |
Off |
Off |
On |
On |
Off |
Off | |
|
D4000h |
Off |
On |
Off |
On |
Off |
Off | |
|
D8000h |
On |
Off |
Off |
On |
Off |
Off | |
|
DC000h |
Off |
Off |
Off |
On |
Off |
Off | |
|
E0000h |
On |
On |
On |
Off |
Off |
Off | |
|
E4000h |
Off |
On |
On |
Off |
Off |
Off | |
|
E8000h |
On |
Off |
On |
Off |
Off |
Off | |
|
EC000h |
Off |
Off |
On |
Off |
Off |
Off | |
|
INTERRUPT REQUEST | ||||||
|
IRQ |
JP1A |
JP1B |
JP1C |
JP1D |
JP1E | |
| » |
3 |
Closed |
Open |
Open |
Open |
Open |
|
2 |
Open |
Open |
Open |
Open |
Closed | |
|
4 |
Open |
Closed |
Open |
Open |
Open | |
|
5 |
Open |
Open |
Closed |
Open |
Open | |
|
7 |
Open |
Open |
Open |
Closed |
Open | |
|
CABLE TYPE | ||||
|
Type |
JP2 |
JP3 |
Pulse Transformer T1 | |
| » |
Unshielded twisted pair |
Open |
Open |
Installed |
|
AUI transceiver via DB-15 port |
Open |
Closed |
Not installed | |
|
DIAGNOSTIC LED(S) | ||
|
LED |
Status |
Condition |
|
LED1 |
On |
Twisted pair network connection is good |
|
LED1 |
Off |
Twisted pair network connection is broken |
|
LED2 |
On |
Data is being received |
|
LED2 |
Off |
Data is not being received |
|
LED3 |
On |
Data is being transmitted |
|
LED3 |
Off |
Data is not being transmitted |
