NIC Type	Ethernet
Transfer Rate	10Mbps
Data Bus	16-bit ISA
Topology	Linear bus
Wiring Type	AUI transceiver via DB-15 port RG-58A/U 50ohm coaxial
Boot ROM	Available

INTERRUPT REQUEST
IRQ		J1A	J1B	J1C	J1D
	2/9	Open	Open	Open	Closed
»	3	Open	Open	Closed	Open
	4	Open	Closed	Open	Open
	5	Closed	Open	Open	Open

I/O BASE ADDRESS
Address		J2A	J2B	J2C	J2D
»	300 - 31Fh	Open	Closed	Closed	Closed
	320 - 33Fh	Open	Closed	Closed	Open
	340 - 35Fh	Open	Closed	Open	Closed
	360 - 37Fh	Open	Closed	Open	Open

BOOT ROM ADDRESS
Address	J3A	J3B	J3C
C000h	Open	Open	Closed
CC00h	Open	Closed	Open
D000h	Closed	Open	Closed

CABLE TYPE
Type		J4	J5A - J5F
»	RG-58A/U 50ohm coaxial	Pins 1 & 2 closed	Pins 2 & 3 closed
	AUI transceiver via DB-15 port	Pins 2 & 3 closed	Pins 1 & 2 closed

COMPATIBILITY MODE
Setting		JP1
»	Disabled	Pins 2 & 3 closed
	Enabled	Pins 1 & 2 closed
Note:On some systems, the data bus timing is not fully IBM PC/AT compatible. If the card is not initializing, enabling the compatibility mode may allow the card to operate normally.
