PLEXTOR
PX-40TSI INTERNAL
|
Device Type |
Internal CD-ROM |
|
Interface |
SCSI |
|
Spin Rate (Read) |
40x |
|
Formats Supported Read |
CD-XA, CD-DA, CD-R, CD-I, CD-ROM (Mode 1 & Mode 2), Photo-CD, Video CD, CD-Plus, CD-E |
|
View |
Top |
|
CONNECTIONS | |
|
Function |
Label |
|
Audio line out |
CN1 |
|
USER CONFIGURABLE SETTINGS | |||
|
Setting |
Label |
Position | |
| » |
Parity check enabled |
JP1/4 |
Closed |
|
Parity check disabled |
JP1/4 |
Open | |
| » |
Termination enabled |
JP1/5 |
Closed |
|
Termination disabled |
JP1/5 |
Open | |
| » |
Factory configured - do not alter |
JP1/6 |
Open |
| » |
Block disabled |
JP1/7 |
Open |
|
Block enabled |
JP1/7 |
Closed | |
| » |
Eject disabled |
JP1/8 |
Closed |
|
Eject enabled |
JP1/8 |
Open | |
|
SCSI SELECT ID | ||||
|
SCSI ID |
JP1/1 |
JP1/2 |
JP1/3 | |
|
0 |
Open |
Open |
Open | |
|
1 |
Closed |
Open |
Open | |
|
2 |
Open |
Closed |
Open | |
| » |
3 |
Closed |
Closed |
Open |
|
4 |
Open |
Open |
Closed | |
|
5 |
Closed |
Open |
Closed | |
|
6 |
Open |
Closed |
Closed | |
|
7 |
Closed |
Closed |
Closed | |
