Card Type	ISDN TA
Chip Set	Unidentified
Transfer Rate	64Kbps x 2
Data Bus	16-bit ISA
ISDN Protocol	Unidentified
Switch Type	5ESS, DMS-100, NI-1

CONNECTIONS
Function	Label	Function	Label
ISDN U-interface out	CN1	DC power	CN3
Handset in	CN2

BASE I/O ADDRESS
Setting		JP1	JP2
»	300h	Open	Open
	320h	Closed	Open
	340h	Open	Closed

MISCELLANEOUS TECHNICAL NOTE

The functions of the LEDs are unidentified.
