Category	Video
Video Types Supported	XVGA
Video Processor	S3 89C801
Highest Resolution Supported	1024 x 768
Data Bus Type	16-bit ISA
Memory Type	DRAM
Maximum Onboard Memory	1024KB

CONNECTIONS
Purpose	Location	Purpose	Location
15-pin analog video port	CN1	VGA feature connector	CN2

INTERRUPT SELECTION
IRQ 2/9		Setting
»	Enabled	Closed
	Disabled	Open

ZERO WAIT STATE SELECTION
Setting		Setting
»	Enabled	Closed
	Disabled	Open

FACTORY CONFIGURED - DO NOT ALTER
Jumper	Setting
JP2	N/A
