Fujitsu MAB3091SC (9.1GB)
3 1/2" 7200 RPM Single Ended Ultra-1 SCSI
A14 / A16 / A20 / A23 / A25 / A26
Netra t 1120 / Netra t 1125 / Netra ft 1800 / Netra t1 / E3000
StorEdge A1000 / StorEdge D1000 / StorEdge A7000
StorEdge MultiPack / StorEdge UniPack
Options 5163 / 5229 / 5230 / 6288 / 6956
| 370-3413 |
| 1" Height Allegro 4L |
| 540-2942 |
540-3704 |
540-3720 |
540-4004 |
RSM FRU
w Bkt 370-2304 |
Spud Bracket FRU
w 1" Bkt 540-3024 |
12-Slot A1000/D1000 FRU
w 1" Bkt 540-3024
w Plate 340-4288 or 340-6640
or Plate 340-5928 or 340-7269 |
Netra ft 1800 FRU |
Notes
- The 9.1GB Drive is not compatible with A7000 Option 9652, Chassis 540-3666.
- The 9.1GB Drive requires A7000 Option 9656, Chassis 540-3841.
Reference
9 Gbyte Disk Drive Specification, 805-3935.
|
