| CODE |
PART # |
DESCRIPTION |
1
-
- |
540-2809
540-2591
340-3360 |
Rack Assembly
 Frame Assembly
 Frame |
2
2 |
300-1290
300-1403 |
Universal Power Sequencer
Universal Power Sequencer |
3
- |
540-2709
540-3271 |
Fan Tray Assembly (-02 with Fingerguards)
Fingerguard Installation Kit for 540-2709-01 |
| 4 |
340-3267 |
Fan Tray Rear Cover |
| 5 |
340-3405 |
Fan Tray Mounting Bracket, Bottom |
| 6 |
340-3434 |
Fan Tray Mounting Bracket, Top |
| 7 |
340-3352 |
Top Panel, Medium Grey |
| 8 |
340-3354 |
Side Panel, Medium Grey |
| 9 |
540-2810 |
Door Assembly with 4 Vented Panels |
| 10 |
540-2746
330-1983
330-1982 |
Top Door Panel Assembly with Blank Filler Insert
Blank Filler Panel Insert
Filler Panel Insert with 4 Tape Drive Cutouts |
| 11 |
540-2393 |
Keyswitch Assembly w Key 330-2014 |
| 12 |
340-3272 |
Door Hinge Bracket |
| 13 |
340-1885 |
Side Restraint Bracket, Upper |
| 14 |
340-1886 |
Side Restraint Bracket, Lower |
| 15 |
340-3355 |
Anti-Tilt Panel, Medium Grey |
| 16 |
230-1418 |
Leveler Foot |
| 17 |
240-1717 |
Caster |
| NS |
340-3394 |
Front Door Catch |
| NS |
340-3353 |
Screw Mounted Rear Panel, Medium Grey |
| NS |
595-4389 |
Hinged Rear Panel Assy (UG-ENT-BKDOOR = 556-3386) |
| NS |
530-1619 |
Ground Cable |
| NS |
530-2234 |
Fan Sense Cable to AC Power Sequencer |
| NS |
530-2236 |
Remote Keyswitch Control Cable, 3.2M |
| NS |
530-2284 |
Keyswitch Cable Extension, Single Sequencer |
| NS |
530-2369 |
Keyswitch Cable Extension, Dual Sequencers |
