Seagate ST373307FC (73.4GB)

3 1/2" 10000 RPM FC-AL

A28 / A29 / A35 / Sun Fire V480 / Sun Fire V880
StorEdge A5200 / StorEdge T3 / StorEdge T3+

Options 6713 / 6742 / 6756 / 6766 / 6805 / 6807

390-0115 390-0121
Cheetah 7
1" Height
Assembly 540-4519		 Cheetah 7
1" Height
Assembly 540-4905
Assembly 540-5408
540-4519 540-4905 540-5408
T3 FRU
w Bkt 540-4303		 Spud Bracket FRU
w 1" Bkt 540-3024
w Plate 340-6640
or Plate 340-7269		 Spud Bracket FRU
w 1" Bkt 540-3024
w Plate 340-6640
or Plate 340-7269

Notes

  1. Drives 390-0115 and 390-0121 have different firmware.
  2. Assembly 540-5408 was released in April 2002.
  3. Drive 390-0115 was added to Assembly 540-5408 in October 2002.
  4. Assembly 540-5408 with 390-0115 fails ESD testing in the Netra 20.
  5. Netra 20 73GB Assembly 540-5694 (released in December 2002) does not include 390-0115.
